X2.055 STD / GE - X2.060 STD / GE

Power Technology. X2.055 X2.060 X2.055 X2.060 Manufacturer Kohler Engine type KDI 1903 TCR Max power (ISO) hp/kW 49 / 36 57 / 42 49 / 36 57 / 42 Engine speed at max power rpm 2600 Max torque Nm 180 200 180 200 Engine speed at max torque rpm 1200 Cylinders / Valves - Displacement cm3 3 / 12 - 1900 Emissions category Stage V Exhaust after-treatment system EGR + DOC + DPF Air intake system turboaftercooler Fuel injection system common rail direct injection Cooling system liquid Engine Memo Switch l Transmission type mechanical Clutch type mechanical No. of gears - FWD+REV l 12+12 - ¡ 16+16 w/creeper Minimum speed m/h l 770 - ¡ 220 (w/creeper) Engine speed at 30 km/h rpm 2600 Type mechanical dry clutch Speeds rpm l 540/540E w/ground speed FRONT AND REAR AXLES Front axle type rigid 4WD Front differential lock l Hydralock Rear braking system l mechanical wet multi-disc HYDRAULIC SYSTEM Hydraul

https://truckmanualshub.com/ X2.055 STD / GE - X2.060 STD / GE https://truckmanualshub.com/ ENGLISH X2.055 X2.060 X2.055 X2.060 STD STD GE GE ENGINE Manufacturer Kohler Engine type KDI 1903 TCR Max power (ISO) hp/kW 49 / 36 57 / 42 49 / 36 57 / 42 Engine speed at max power rpm 2600 Max torque Nm 180 200 180 200 Engine speed at max torque rpm 1200 Cylinders / Valves - Displacement cm3 3 / 12 - 1900 Emissions category Stage V Exhaust after-treatment system EGR + DOC + DPF Air intake system turboaftercooler Fuel injection system common rail direct injection Cooling system liquid Engine Memo Switch l CAPACITIES Fuel tank l 40 TRANSMISSION Transmission type mechanical Clutch type mechanical No. of gears - FWD+REV l 12+12 - ¡ 16+16 w/creeper Minimum speed m/h l 770 - ¡ 220 (w/creeper) Engine speed at 30 km/h rpm 2600 REAR PTO Type mechanical dry clutch Speeds rpm l 540/540E w/ground speed FRONT AND REAR AXLES Front axle type rigid 4WD Front differential lock l Hydralock BRAKING SYSTEM Rear braking system l mechanical wet multi-disc HYDRAULIC SYSTEM Hydraulic circuit type - Pump type open center - twin pump Flow rate - rear hitch & remotes + steering l/min 35+20 Rear remote valves l 2…
