WA TADANO 5

150 Ton Capacity (136 Metric Tons) 188,98" (4,800) 41'0,13"(12,500) = — _- __ -- _ -- — "4! TADANO 8 me ae) |___7'6.55"(2,300) 4.792.560) ae 6,93" (1,700) | 5 8.90"(1,750) $4.6" (1,660)|5 1.81" (1,670 16.5. 14'7.71" (4,463) 41239" 26 0.99" (7,950) (100) 11,280) 39° 4,44" (12,000) LL. AT 8.83" (14,550) 50'5.20"(15,372) 8 7.46" (2,628)! 10' 5,98" (3,200) 26 2.96"18,000) Steering Front Wheel All Wheel Inside 21.0 ft (6.4m) | 12.1 ft (3.7m) Carrier 43.0 ft (13.1m) | 33.5 ft (10.2m) LL Over boom extension | 48.2 ft (14.7m) | 39.0 ft (11.9m)) Specifications are subject to change without notice. 1. CRANE CARRIER The chassis frame is a torsion and bend resistant box type welded construction made of high tensile steel. A support ring with tapped holes is integrated in the upper plate for mounting the triple roller bearing slewing ring. Double box type outrigger casings are in- tegrated at the
