28-B: Band Saw Instruction Sheets

Revised 1-15-58 U. S. Patent No. 2,032,233; 2,108,086; 2,193,946 14” WOOD CUTTING AND METAL-WOOD CUTTING Operating and Maintenance Instructions METAL-WOOD CUTTING MODELS A band saw requires a reasonable amount of care and attention in order to insure perfect performance and accurate work. No matter how good a machine a manufacturer may make, it will not do its best work unless the user takes the trouble to familiarize himself with the proper method of using the machine and set- ting the adjustments, and to learn what is necessary for best results. It takes but a few minutes to read these instructions, and it may save hours of trouble or The gear case of the metal-wood cutting Band Saw contains a double clutch which permits instant change-over from gear drive to direct drive by simply shifting the clutch. Metal- Wood & Wood Cutting Models Remove the carton and weatherproof covering and pl

Power Tools PM-1827 Revised 1-15-58 28-B: Band Saw Instruction Sheets U. S. Patent No. 2,032,233; 2,108,086; 2,193,946 14” WOOD CUTTING AND METAL-WOOD CUTTING BAND SAW Operating and Maintenance Instructions METAL-WOOD CUTTING MODELS A band saw requires a reasonable amount of care and attention in order to insure perfect performance and accurate work. No matter how good a machine a manufacturer may make, it will not do its best work unless the user takes the trouble to familiarize himself with the proper method of using the machine and set- ting the adjustments, and to learn what is necessary for best results. It takes but a few minutes to read these instructions, and it may save hours of trouble or delay later. The gear case of the metal-wood cutting Band Saw contains a double clutch which permits instant change-over from gear drive to direct drive by simply shifting the clutch. SETTING UP Metal- Wood & Wood Cutting Models Remove the carton and weatherproof covering and place saw on stand or bench. Loosen table clamp and set table horizontal. The table insert and the tapered pin for the table alignment hole at the end of the table slot, together with the hexagon wrench for the…
