Domestic type roll-up garage door operator Installation manual Revision Oct.08.002 support@et. Technical specifications may change without prior notice. All goods are subject to the standard factory warranty as laid out on the last page of this publication G&C Electronics cc. T/A ET Systems 15 Nelson Rd, Observatory, Cape Town, South Africa We strongly recommend that a set of safety infra red beams (ET BLUE I’s) be used for additional DO NOT operate the Garage door operator while a person, especially a child is near the door. Children must be under adult supervision at all times near an automated garage door especially whilst the operator is in use. Ensure that the BUILT IN SAFETY OBSTRUCTION SENSING SYSTEM (Load sensing) is correctly setup. Regular testing (Monthly) is advised and adjustment must be made if necessary. DO NOT pull the Manual release cord that changes the operator to

ET BLUE-ROLL Domestic type roll-up garage door operator Installation manual Revision Oct.08.002 support@et.co.za Technical specifications may change without prior notice. All goods are subject to the standard factory warranty as laid out on the last page of this publication G&C Electronics cc. T/A ET Systems 15 Nelson Rd, Observatory, Cape Town, South Africa www.et.co.za 1 We strongly recommend that a set of safety infra red beams (ET BLUE I’s) be used for additional protection. DO NOT operate the Garage door operator while a person, especially a child is near the door. Children must be under adult supervision at all times near an automated garage door especially whilst the operator is in use. Ensure that the BUILT IN SAFETY OBSTRUCTION SENSING SYSTEM (Load sensing) is correctly setup. Regular testing (Monthly) is advised and adjustment must be made if necessary. DO NOT pull the Manual release cord that changes the operator to manual operation whilst any person or object is near or under the path of the door. If possible always change the operator to manual mode with the door in the full closed position. Connect the operator’s 220Vac mains cord to properly earthed mains.…
