Akai MPC500 SERVICE MANUAL

MODEL: MPC500 (AKAI) Display: 2 x 16 charatec LCD w/back light Memory card slot: Compact Flash (The size of the compact flash card that MPC500 can handle if from 32MB to 2 GB) Dimensions: 266mm x 175mm x 44mm Power requiremtn: 12v DC 600mA (negative tip) Battery life: Approximately 4.5 hour of continuous use with LCD backlight „ Sound Generator Sampling rate: 44.1kHz Memory capacity: 16MB standard (11.5MB for sound memory), expandable to 128MB Recording time: 136sec. (16MB, MONO); 24M28sec. (128MB,MONO) Memory expansion slot: 1 x for optional EXM128 Data format: 16-bit linear Polyphony: up to 32 (dependent on processing) Dynamic filtering: 2-pole lowpass filter per voice Preset sound memory: 5MB Number of programs: 24 Effects: 2 stereo effects and Master effect Effect type: Chorus, Flanger, Bit grunger, 4 band EQ, Compressor, phase shifter, Tremolo, Flying pan, Reverb, Delay Master eff

SERVICE MANUAL MODEL : MPC500 (AKAI) Specification „ General Display: 2 x 16 charatec LCD w/back light Memory card slot: Compact Flash (The size of the compact flash card that MPC500 can handle if from 32MB to 2 GB) Dimensions: 266mm x 175mm x 44mm Weight: 1.34kg Power requiremtn: 12v DC 600mA (negative tip) Battery life: Approximately 4.5 hour of continuous use with LCD backlight „ Sound Generator Sampling rate: 44.1kHz Memory capacity: 16MB standard (11.5MB for sound memory), expandable to 128MB Recording time: 136sec. (16MB, MONO) ; 24M28sec. (128MB,MONO) Memory expansion slot: 1 x for optional EXM128 Data format: 16-bit linear Polyphony: up to 32 (dependent on processing) Dynamic filtering: 2-pole lowpass filter per voice Preset sound memory: 5MB Number of programs: 24 „ Effects Effects: 2 stereo effects and Master effect Effect type: Chorus, Flanger, Bit grunger, 4 band EQ, Compressor, phase shifter, Tremolo, Flying pan, Reverb, Delay Master effect: 4 band EQ, Compressor „ Sequencer Maximum events: 100,000 notes Resolution: 96 parts per 1/4-note Sequences: 99 Tracks per sequence: 48 MIDI output channels: 16 Song mode: 20 songs, 250 steps per song Drum pad: 12 (velocity and…
