EML 101 SERVICE MANUAL ocr

PANEL JACKS EML 101 (Listed from left to right) (Arrows down - inputs; arrows up - outputs) + VOLTS (output) Constant voltage source; stereo output, +10 V, -10 V, nominal. Glide (input) Used with optional101 foot switch for turning glide on and Gate (output) A voltage source of approximately 15 volts which is "turned on" for every key depression. When a key is depressed, the GATE VOLTAGE immediately goes to +15 V and will remain at that level for as long as the key is "down". The GATE may be used to initiate envelopes of the 101,"step" a Sampler, initiate external add-on control functions (Envelope, Sampler, Sequencer) of the EML 200, EML 401 module, and EMし 400 Series Sequencer. CM 2 (output) Keyboard 1 control voi tage Lowest key - 4.4 volts (+10%) Highest key - 8.8 volts て土 10幻 Sequencer (input) EML 400 Series Sequencer quantized, exponential, or linear voltage input for pitch contro

PANEL JACKS EML 101 (Listed from left to right) (Arrows down - inputs; arrows up - outputs) KEYBOARD + VOLTS (output) Constant voltage source; stereo output, +10 V , -10 V, nominal. Glide (input) Used with optional101 foot switch for turning glide on and off. — Gate (output) A voltage source of approximately 15 volts which is "turned on" for every key depression. When a key is depressed, the GATE VOLTAGE immediately goes to +15 V and will remain at that level for as long as the key is "down". The GATE may be used to initiate envelopes of the 101,"step" a Sampler, initiate external add-on control functions (Envelope, Sampler, Sequencer) of the EML 200, EML 401 module, and EMし 400 Series Sequencer. CM 2 (output) Keyboard 1 control voi tage Lowest key - 4.4 volts (+10%) Highest key - 8.8 volts て土 10幻 Sequencer (input) EML 400 Series Sequencer quantized, exponential, or linear voltage input for pitch control of Oscillators 3 and 4. Oscillator 3 must be in the KB2 mode, Oscillator 4 in CM3 mode. OSCILLATOR CONTROL MIXER External (input) Used to introduce external control voltage sources into the oscillator control mixer. Patching an external control source into EXT, negates the…
