STANDARD FEATURES

800-428-5655 • 4,400 lb. (1,996kg) and 5,000 lb. (2,268kg) Capacity at 24" (600mm) Load Center • Lift Heights to 492" (12.5M) • Four-Wheel Design, Dual Rear Wheel Drive • High Visibility 3-Stage Mast • Integral 11.2" (285mm) Stroke Side Shifter and 36" (914mm) High Load Backrest • Adjustable Seat and Steering Wheel • Dual Curtis AC Traction Motor Controllers • Curtis AC Hydraulic Motor Controller • Battery Discharge Indicator with Lift Interrupt • Electronic Regenerative and Hydraulic Disc Braking • “Floating” Articulated Front Axle • 180º Front-End DuraSteer™ Articulation / Steering Assembly with 5-Year Warranty • Safety Seat Switch, Seat Belt and Rear View Mirror • Curtis Engage Dash Display • Hand Actuated Parking Brake • Non Tilting Rigid Mounted Mast • Carriage Tilt 0º Forward / 3º Backward • Smooth Rubber Drive Tires • Soft Polyurethane Load Wheel Tires • 40" (1

https://truckmanualshub.com/ 800-428-5655 www.landoll.com/mhp STANDARD FEATURES • 4,400 lb. (1,996kg) and 5,000 lb. (2,268kg) Capacity at 24" (600mm) Load Center • Lift Heights to 492" (12.5M) • Four-Wheel Design, Dual Rear Wheel Drive • High Visibility 3-Stage Mast • Integral 11.2" (285mm) Stroke Side Shifter and 36" (914mm) High Load Backrest • Adjustable Seat and Steering Wheel • Dual Curtis AC Traction Motor Controllers • Curtis AC Hydraulic Motor Controller • Battery Discharge Indicator with Lift Interrupt • Electronic Regenerative and Hydraulic Disc Braking • “Floating” Articulated Front Axle • 180º Front-End DuraSteer™ Articulation / Steering Assembly with 5-Year Warranty • Safety Seat Switch, Seat Belt and Rear View Mirror • Curtis Engage Dash Display • Hand Actuated Parking Brake • Non Tilting Rigid Mounted Mast • Carriage Tilt 0º Forward / 3º Backward • Smooth Rubber Drive Tires • Soft Polyurethane Load Wheel Tires • 40" (1,000mm) Tapered Tip Forks - Rear Tow Hitch Pin • Three Section Hydraulic Control Valve • Meets ANSI B56.1 OPTIONAL FEATURES • Non-Standard Fork Lengths • Dual Overhead Guard-Mounted LED Headlights • Dual Rear Safety LED Light Bars • Safety Flashing LED…
