Cummins IS – Interact System

Cummins IS – Interact System & HPI-TP Fuel System Cummins 3rd generation of electronics was introduced in 1997 under the IS management system. ISX CM870 engine control system The Electronic Control Module is the control center of the system. The ECM processes all of the inputs and sends commands to the fuel system, vehicle, and engine control devices. Because the ECM is the final pathway of integration for all vehicle management systems, it is called interact or IS for short. IS From Cummins includes some of the following features y Faster processing speeds and increased memory y Improved fuel efficiency y Integrated Centinel Control (no separate module) y Improved Maintenance Monitor features y Enhanced PTO programming features/ parameters y Enhanced engine diagnostics/Prognostics y Enhanced Security features y Enhanced Engine Protection System y Anti theft protection when used with Roa

Cummins IS – Interact System & HPI-TP Fuel System Introduction Cummins 3rd generation of electronics was introduced in 1997 under the IS management system. ISX CM870 engine control system The Electronic Control Module is the control center of the system. The ECM processes all of the inputs and sends commands to the fuel system, vehicle, and engine control devices. Because the ECM is the final pathway of integration for all vehicle management systems, it is called interact or IS for short. IS From Cummins includes some of the following features y Faster processing speeds and increased memory y Improved fuel efficiency y Integrated Centinel Control (no separate module) y Improved Maintenance Monitor features y Enhanced PTO programming features/ parameters y Enhanced engine diagnostics/Prognostics y Enhanced Security features y Audit trails y Enhanced Engine Protection System y Anti theft protection when used with Road Relay y Powertrain Protection Features y J-1939 Network capable y Enhanced On-Board Trip Information y Battery Powered ECM clock back-up for real time clock stamping of data. y Enhanced data reporting features y Short Range Radio Communication (“Inrange” SRRF) System y…
