PACCAR MX-13 engines The 12.9 litre Euro 6 PACCAR MX-13 engine uses ultra-modern common rail technology, a turbo with variable geometry and advanced controls for maximum efficiency. In order to comply with the strict Euro 6 emissions requirements, it features exhaust gas recirculation, together with SCR technology and an active soot filter. The engines provide additional torque at low revs in the highest gear for direct drive gearboxes and in the two highest gears for overdrive gearboxes to support lower fuel consumption of the vehicle. Engine Output - kW (hp) Torque - Nm MX-13 315 315 (428) at 1600 rpm 2300 at 900-1125 rpm1] 2150 at 900-1365 rpm MX-13 355 355 (483) at 1600 rpm 2500 at 900-1125 rpm1] 2350 at 900-1365 rpm MX-13 390 390 (530) at 1675 rpm 2600 at 1000-1460 rpm1] 2500 at 1000-1425 rpm 1] in the highest gear for direct drive gearboxes and in the two highest gears for overdrive

https://truckmanualshub.com/ PACCAR MX-13 engines The 12.9 litre Euro 6 PACCAR MX-13 engine uses ultra-modern common rail technology, a turbo with variable geometry and advanced controls for maximum efficiency. In order to comply with the strict Euro 6 emissions requirements, it features exhaust gas recirculation, together with SCR technology and an active soot filter. The engines provide additional torque at low revs in the highest gear for direct drive gearboxes and in the two highest gears for overdrive gearboxes to support lower fuel consumption of the vehicle. Engine Output - kW (hp) Torque - Nm MX-13 315 315 (428) at 1600 rpm 2300 at 900-1125 rpm1] 2150 at 900-1365 rpm MX-13 355 355 (483) at 1600 rpm 2500 at 900-1125 rpm1] 2350 at 900-1365 rpm MX-13 390 390 (530) at 1675 rpm 2600 at 1000-1460 rpm1] 2500 at 1000-1425 rpm 1] in the highest gear for direct drive gearboxes and in the two highest gears for overdrive gearboxes General information Six-cylinder in-line turbocharged diesel engine with intercooling. Ultra clean combustion with Exhaust Gas Recirculation (EGR), Diesel Particular Filter (DPF) and Selective Catalytic Reduction (SCR) aftertreatment for Euro 6 emission…
