01-02

Overall working weight kg 17,300 Front and Rear Axles TYPE FULLY FLOATING PLANETARY-TYPE Capacity heaped ISO/SAE m3 3.0 FIXED MOUNTING(FRONT) Rated load kg 5000 TRUNNION MOUNTING(REAR) Max traction force Ton 17 Final decelerate type PLANETARY Max breakout force (kN) kN 161 lbf 36,194 Tyre Max gradability Degree 30 Tyre specification 23.5 -25-16PR Dump height (at 45º) 1) mm 3085 Front tyre pressure Mpa 0.38 (at fully raised) Rear type pressure Mpa 0.34 Dump reach (at 45º) 1) mm 1,297 Steering System Wheel Loader(at fully raised) ft in 4'2" SD310 Overall dimension(LxWxH) mm 8260×2992×3450 Steering angle degree 40 Engine Min. turning radius mm 5800 (outside tires) ft in 19'0" Model Doosan DE08TIS (TIER-II Certified) Min. turning radius mm 6510 Type TURBO, DIRECT INJECTION (outside bucket) ft in 21'4" Number of cylinder 6 Bore/stroke (mm) 111 X 139 (mm) Hydraulic system Max torque 902 N.m/13

https://truckmanualshub.com/ Specification Overall working weight kg 17,300 Front and Rear Axles lb 38,140 TYPE FULLY FLOATING PLANETARY-TYPE Capacity heaped ISO/SAE m3 3.0 HUB DRIVE yd3 3.9 FIXED MOUNTING(FRONT) Rated load kg 5000 TRUNNION MOUNTING(REAR) Max traction force Ton 17 Final decelerate type PLANETARY Max breakout force (kN) kN 161 lbf 36,194 Tyre Max gradability Degree 30 Tyre specification 23.5 -25-16PR Dump height (at 45º) 1) mm 3085 Front tyre pressure Mpa 0.38 (at fully raised) Rear type pressure Mpa 0.34 ft in 10'1" Dump reach (at 45º) 1) mm 1,297 Steering System Wheel Loader(at fully raised) ft in 4'2" SD310 Type Gear Overall dimension(LxWxH) mm 8260×2992×3450 Steering angle degree 40 Engine Min. turning radius mm 5800 (outside tires) ft in 19'0" Model Doosan DE08TIS (TIER-II Certified) Min. turning radius mm 6510 Type TURBO, DIRECT INJECTION (outside bucket) ft in 21'4" Number of cylinder 6 Bore/stroke (mm) 111 X 139 (mm) Hydraulic system Max torque 902 N.m/1300 rpm System working pressure bar 170 Rated power 160kW(215HP)/2,000 rpm Boom lifting(full load) sec < ~ 6.0 Rated speed 2000 rpm Total time sec < ~ 11.3 Min fuel consume ratio 215 g/kw.h @ RATED SPEED…
