Diamond T969 Spare Parts Catalog.pdf

Diamond T 969 was a vehicle recovery truck based on a 4 ton 6x6 chassis, powered with a Hercules RXC six-cylinder gasoline engine and equipped with a five-speed overdrive transmission and a direct and under drive transfer, manufactured from roughly 1940 until 1945 by the Diamond T Motor Car Company in Chicago. The wrecker carried a heavy duty set of Holmes W45 Twin Boom Wrecker gear, designed in the inter-war period for civilian breakdown trucks. Either boom as a normal crane but together the booms provided a greater lifting capacity at the rear of the vehicle. The wrecker was fitted with stabiliser legs on each side to keep the vehicle upright when the booms were used for side lift. This also saved the necessity of using the opposite boom as an anchor. The lifting winches were power operated, rated at 10 000 Ibs. Linked together, a lift of 10 US tons was possible, but to s
