333514B Komatsu PC210/PC240/PC290 and PC360/PC390/PC490 Excavator Installtion Instructions

Instructions for install a Graco automatic lubrication systemon a Komatsu PC210/PC240/PC290 and PC360/PC390/PC490 Excavator

https://truckmanualshub.com/ Mobile Lubrication Library Komatsu PC210-11/PC240-11/PC290-11 and PC360-11/ PC390-11/PC490-11 Excavator Installation Instructions Instructions for installing a Graco automatic lubrication system on a333514B Komatsu PC210-11/PC240-11/PC290-11 and PC360-11/PC390-11/PC490-11 Excavator. Part No. 17J900 Maximum System Working Pressure: 2750 psi (18.96 MPa, 189.6 bar) Important Safety Information Read all warnings and instructions in all Graco related component manuals and all WARNING Komatsu equipment manuals. Save all FLUID INJECTION HAZARD instructions. Fluid leaks from incorrectly installed or ruptured components, and/or failure to verify the compo- Related Graco Component Manuals* nents are properly installed and tested, can result in serious injury such as fluid spraying in Manual No. Manual Title the eyes or on skin and fluid injection, or equip- 332291 G3 Pump ment damage. Installation must be done by a 3A2960 GLC2200 Controller qualified professional or Komatsu certified tech- nician and tested prior to use. 312497 MSP Divider Valves *Refer to these instruction manuals for additional infor- mation related to the installation and operation of system…
