5 BRAKES B1700·B2100·B2400 WSM,11770

[2] BRAKE ASSEMBLY DISASSEMBLING AND ASSEMBLING (1) Separating Rear Axle Case with Brake Assembly Drain the Transmission Fluid 1. Place oi I pans underneath the transmission case. 2. Remove the four drain plugs (1). 3. Drain the transmission oil. 4. Reinstall the four drain plugs (1). (When refilling) • Fill up from filling port after removing plug (2) until reaching • After running the engine for few minutes, stop it and check the oil level again. Add the oil to prescribed level if it is not HSTtype 3.17 Transmission oil capacity 111 Manual 2.9 tra nsmission type • Use only multi-grade transmission oil. Use of other oils may damage the transmission or hydraulic system. Refer to "LUBRICANTS AND FLUID" (See page G-8). • Never work the tractor immediately after changing the transmission oil. Keeping the engine at medium speed for a few minutes to p

https://truckmanualshub.com/ 5 BRAKES B1700·B2100·B2400 WSM,11770 [2] BRAKE ASSEMBLY DISASSEMBLING AND ASSEMBLING (1) Separating Rear Axle Case with Brake Assembly Drain the Transmission Fluid 1. Place oi I pans underneath the transmission case. 2. Remove the four drain plugs (1). 3. Drain the transmission oil. 4. Reinstall the four drain plugs (1). (When refilling) • Fill up from filling port after removing plug (2) until reaching the gauge (3). • After running the engine for few minutes, stop it and check the oil level again. Add the oil to prescribed level if it is not correct level. 121 HSTtype 3.17 U.S.gals 2.6Imp.gals Transmission oil capacity 111 Manual 2.9 U.S.gals tra nsmission type 2.4lmp.gals II IMPORTANT • Use only multi-grade transmission oil. Use of other oils may damage the transmission or hydraulic system. Refer to "LUBRICANTS AND FLUID" (See page G-8). • Never work the tractor immediately after changing the transmission oil. Keeping the engine at medium speed for a few minutes to prevents damage to the transmission. • Do not mix different blands oil together. (A) Oil level acceptable within this range. (1) Drain Plug (3) Gauge (2) Filling Plug B177FG06 5-54…
