SHOP MANUAL

Paragraphs 73-74. Check plate bolt. Range shift lever; Front-wheel drive Fig. 73— Exploded view of shifter mechanism used on Models B5100D and B5100E. Components 35 through 44 are used on Model B5100D and components 46 and 47 are used on Model 85100E. UDT hydrostatic transmission fluid, Shell Donax-TD or TM, Mobil Fluid 350, Exxon Torque Fluid 56. Bleed fuel system as outlined in paragraph 36. REMOVE AND REINSTALL 73. Split clutch housing from trans- mission case as outlined in paragraph 72. Remove shift cover (11-Fig. 73 or Fig. 74) as an assembly with shift com- ponents. Remove hydraulic lift covers as outlined in paragraph 99. Remove cap screws and nuts securing gear transmis- sion case to center housing. Separate assemblies, then withdraw transmission assembly while being careful not to allow any component to fall free. Installation is reverse order of removal. Tighten cap screws
